Views: 12 Author: Site Editor Publish Time: 2024-12-09 Origin: Site
When you have a short frame Centrifugal pump, what different spare parts do you need?
The short frame Centrifugal Pump, in MISSION, which is called a MISSION SandMaster Pump.
The compact and adaptable Sandmaster Centrifugal Pump includes virtually all of the features of the Magnum I. Sandmasters are more compact in design and can be adapted for hyraulic motor drive. These features make Sandmaster pumps ideal for use in applications such as oilfield frac trucks as well as blending and pump charging for water well drilling applications.
All parts for these pumps are identical to the Magnum except for the frame and the shaft. The frame and the shaft have been shortened 4” to reduce the length of the pump. When space is a premiumand prime mover options are limited, the Sandmaster pump is the pump of Choice.
Parts for short pump
ITEM | Evergrow No. | Mission No. | DESCRIPTION | Material |
1 | S023939 | 20939-02-33 | Shaft, Short pump | 42CrMo |
2 | S021938 | 20938-02-1 | Frame, Short pump | HT250 |
3 | S014324 | 22224-01-43 | Housing, Hydraulic Outboard Bearing | QT700 |
4 | S011225 | 22225-01-01 | Adapter, Hydraulic Drive | QT500 |
Parts for Short Pumps (All parts for short pumps are identical to the EG-250 except the above) | ||||
Common applications include:
Cement
Charge Pump
Blender
Waterwell Drilling
Other Mobile uses
EVERGROW can supply all spare parts for 250 series centrifugal pumps, welcome to contact our sales team for further information.
