EVERGROW can supply XBSY Centrifugal Pumps and spare parts, please find the past list that we can do:
| Item | Decription | Part No. | Drawing No. | QTY |
| 1 | Plug ZG1/2” | X01173002 | SB68FJ0001 | 5 |
| 2 | Casing | X01177002（Chinese Flange） | SB68FJ0002 | 1 |
| X01277002（American Flange） |
| 3 | Impeller-J | 50Hz | 45kW | X01171002 | SB68FJ0003 | 1 |
| 55kW | X01172002 |
| 75kW | X01173004 |
| 60Hz | 45kW | X11171002 |
| 55kW | X11172002 |
| 75kW | X11173004 |
| 4 | Impeller Acorn Nut M30×2-LH | X01173005 | SB68FJ0004 | 1 |
| 5 | Impeller Nut M30×2-LH | X01173006 | SB68FJ0005 | 1 |
| 6 | Impeller flat washer,30 | W05010030 | SB68FJ0006 | 1 |
| 7 | Casing Gasket | X01173008 | SB68FJ0007 | 1 |
| 8 | Stud, M16×75 | W01402180 | SB68FJ0008 | 12 |
| 9 | Springwasher,16 | W05101016 | SB68FJ0009 | 12 |
| 10 | Nut M16 | W03012016 | SB68FJ0010 | 12 |
| 11 | Mechanical seal stuffing box | X01173009 | SB68FJ0011 | 1 |
| 12 | Bolt M12×35 | W01012123 | SB68FJ0012 | 8 |
| 13 | Springwasher, 12 | W05101012 | SB68FJ0013 | 8 |
| 14 | Bearing Cover Gasket | X01173010 | SB68FJ0014 | 2 |
| 15 | Inboard Bearing, 7314ACM | W21157314 | SB68FJ0015 | 2 |
| 16 | Oil Plug | X01173011 | SB68FJ0016 | 1 |
| 17 | Shaft | X01173012 | SB68FJ0017 | 1 |
| 18 | Rivet, 2×6 | W40595026 | SB68FJ0018 | 4 |
| 19 | Nameplate | W99116001 | SB68FJ0019 | 1 |
| 20 | Grease Fitting, M10×1 | 90° | W16010010 | SB68FJ0020 | 1 |
| 45° | W16070010 | 1 |
| 21 | Bolt, M8×16 | W01012889 | SB68FJ0021 | 8 |
| 22 | Springwasher 8 | W05101008 | SB68FJ0022 | 8 |
| 23 | Oil seal FB65×90×12 | W12124653 | SB68FJ0023 | 3 |
| 24 | Outboard Bearing, 6314E | W21156314 | SB68FJ0024 | 1 |
| 25 | Crclip for shaft,70 | W05293070 | SB68FJ0025 | 1 |
| 26 | Outboard bearing Cover baffle | X01173013 | SB68FJ0026 | 2 |
| 27 | Outboard bearing cover | X01173014 | SB68FJ0027 | 1 |
| 28 | Frame | X01173015 | SB68FJ0028 | 1 |
| 29 | Oil Level Gauge M20×1.5 | W17000020 | SB68FJ0029 | 1 |
| 30 | Inboard bearing gasket | W29010068 | SB68FJ0030 | 1 |
| 31 | Bearing Lock nut M68×2-LH | W03370069 | SB68FJ0031 | 1 |
| 32 | Bearing Lock washer, 68 | W05252068 | SB68FJ0032 | 1 |
| 33 | Inboard Bearing Cover | X01173017 | SB68FJ0033 | 1 |
| 34 | Deflector | W99131101 | SB68FJ0034 | 1 |
| 35 | Gland set | X01173018 | SB68FJ0035 | 1 |
| 36 | Shaft sleeve | X01173020 | SB68FJ0036 | 1 |
| 37 | O-ring Φ55×3.1 | W1111550C | SB68FJ0037 | 1 |
| 38 | Packing, 12×12 | W11311112 | SB68FJ0038 | 2 |
| 39 | Gland bolt, M12×80 | W01144131 | SB68FJ0039 | 2 |
| 40 | Flat washer, 12 | W05031012 | SB68FJ0040 | 2 |
| 41 | Bolt, M10×45 | W01012095 | SB68FJ0041 | 2 |
| 42 | Nut, M10 | W03012010 | SB68FJ0042 | 2 |
| 43 | Rotated-proof Pin | X01173021 | SB68FJ0043 | 1 |
| 44 | Mechanical Seal | W13110002 | SB68FJ0044 | 1 |
| 45 | Impeller key C14×70 | W08021470 | SB68FJ0045 | 1 |
| 46 | Shaft Sleeve Key C6×25 | W08120625 | SB68FJ0046 | 1 |
For further details, please contact our sales team by amber@linhaievergrow.com
