EG5-2500 Quintuplex Plunger Pump applicable for Fracturing, Cementing, Sand proof, acidizing, etc. Compared with the same rated power TWS pump, The pump's volume and weight increased a lot, but its displacement increased by nearly 1.7 times, so the work efficiency is much higher. The pump also adopts “人” shape tear reducer, its operation is stable and reliable.
Specification
Max Brake Horsepower | 2500BHP(1864KW) |
Connection Rod Load(Max) | 192,325lbf (855.5KN) |
Stroke Length | 8" (203.2mm) |
Transmition | Double Cylinder Gear |
Speed Ratio | 6.353:1 |
Size-LxWxH | 86.65*79.27*45.7 in 2201*2013*1161mm |
Weight | 16,093 lb(7,300kg) |
